GERMAN Amateur Radio Station DF6DP, Matthias Roxer

Weather satellite images recorded at Hagen, QTH LOCATOR JO31RI, Germany.

Latitude: 51.361, Longitude: 7.447

Software: WXtoImg version 2.10.11

Receiver: R2FX

Antenna: Turnstile

Click on any image below for a full sized image. Times are shown in UTC.

Next Scheduled Satellite Passes over Hagen, QTH LOCATOR JO31RI, Germany

Satellite
Name
Start of Pass Time Available Direction Maximum Elevation
Degrees (East or West)
Frequency
MHz
UTC Local Time* UTC Local Time*
NOAA 15 22 Jun 06:22 22 Jun 08:22 22 Jun 06:38 22 Jun 08:38 137.62
NOAA 18 22 Jun 07:12 22 Jun 09:12 22 Jun 07:27 22 Jun 09:27 137.9125
NOAA 15 22 Jun 08:03 22 Jun 10:03 22 Jun 08:16 22 Jun 10:16 137.62
NOAA 18 22 Jun 08:53 22 Jun 10:53 22 Jun 09:08 22 Jun 11:08 137.9125
NOAA 19 22 Jun 12:51 22 Jun 14:51 22 Jun 13:00 22 Jun 15:00 137.10
NOAA 19 22 Jun 14:27 22 Jun 16:27 22 Jun 14:43 22 Jun 16:43 137.10
NOAA 15 22 Jun 16:09 22 Jun 18:09 22 Jun 16:22 22 Jun 18:22 137.62
NOAA 19 22 Jun 16:10 22 Jun 18:10 22 Jun 16:28 22 Jun 18:28 137.10

* local time is Mitteleuropäische Sommerzeit.


About the Enhancements

This page shows just several of the 35 enhancements WXtoImg provides:

MSA Multi-Spectral Analysis: combines a sensor 1 or 2 (visible/near infrared) image with a sensor 4 (thermal infrared) image to create a
near true colour, near visible image of the earth.
MCIR-precip Map Coloured IR with Precip: uses sensor 4 (thermal infrared) to create a false coloured image showing areas of likely precipitation.
The likelihood and intensity of precipitation increases as the colour goes from green to yellow to orange to red to black to white.
SST (sea) Sea Surface Temperature: creates a false coloured image using the temperatures from a sensor 4 (thermal infrared) image. The black areas indicate land and cold cloud.
HVCT HVCT false colour: creates a false coloured image by combining a sensor 1 or 2 (visible/near infrared) image with a sensor 4
image (thermal infrared) to create an image in which clouds are tinted by their temperature.
Thermal Thermal: creates a false coloured image using the temperatures from a sensor 4 (thermal infrared) image. Covers the full range of temperatures from very cold cloud tops to hot deserts.
Pristine These are images as they come from the satellite without alteration. The earth appears "upside down" on Northbound passes.
The two images are the two channels sent by the satellite with channel A (left) switching between sensor 1 (visible) or 2 (near-IR)
during the day and sensor 3 (mid-IR) at night and channel B (right) showing sensor 4 (thermal-IR) at all times during
normal operation.
